Product Details:
|
| Material: | Tungsten Carbide | Coated: | Nano |
|---|---|---|---|
| Standard: | Long Neck | Hardness Degree: | HRC65 |
| Series: | SX | Flute: | 2 Flutes |
| Flute Dia.: | 1.5mm | Flute Length: | 3mm |
| Neck Length: | 8 | Shank Dia.: | 4mm |
| Helix Angle: | 35° | Overlength: | 50mm |
| Shank Shape: | Straight Shank | ||
| High Light: | 2 flute carbide end mill Hrc65,solid carbide 2 flute straight end mill,2 flute carbide end mill 1.5mm Square |
||
The SX series is for high hardness steel . It can provide a perfect lifespan and a precision tolerance. It can be general purpose or high perfomance, and be used for plunging, grooving, side milling, face milling, and counter boring. We can exceeds expectations in aggressive cutting parameters & advanced operations.The end mills are more productive, they can Improved chip evacuation & increased edge/corner strength to reduce any risk of breakage.
| Material: | Tungsten Carbide |
| Standard: | Long Neck |
| Series: | SX |
| Flute Dia.: | 1.5mm |
| Neck Length: | 8 |
| Helix Angle: | 35° |
| Shank Shape: | Straight Shank |
| Coated: | Nano |
| Hardness Degree: | HRC65 |
| Flute: | 2 Flutes |
| Flute Length: | 3mm |
| Shank Dia.: | 4mm |
| Overlength: | 50mm |
The above specifications are standard Size, with a large amount of stock. At the same time, we support OEM customized production, the diameter is 0.2mm to 25mm, the Total length is 50mm to 200mm, include inch size end mill , the number of Flute is 4F, 5F, 6F, 8F and the logo could becustomized.
